European electric hoist adopts European FEM design standards and is a product developed in combination with current advanced technology. The whole machine has compact and reasonable structure, simple and convenient operation, safe and reliable operation, and meets the requirements of contemporary low noise, energy saving and environmental protection.
The overall layout of the European electric hoist is a parallel C-type structure, that is, the reel device is arranged in parallel with the motor through the reducer, so that the length of the hoist is small, the limit size is small, the structure is compact, and the force position is good, which provides the installation and maintenance of the motor reducer. space convenience.
This series of electric hoists is equipped with an overload limiter, and can also realize loss-of-voltage protection, phase-misalignment protection, precise upper and lower limit positions, cumulative count of the number of uses, and real-time storage of running information and status information, making this series of electric hoists more secure. Reliability, greatly reducing or eliminating the possibility of accidents.
Design, production and inspection carry out the last issued relevant national standard, equivalently adopts some foreign criteria including FEM. DIN and IEC. Compared with the general QD bridge crane, its weight is reduced by about 15~30%, the maxinum wheel pressure is reduced by about 10~35%, which can the reouesments of crane for factory building structure and reduce production cost. As the core component of drivng mechansm, reducer gear pair with hard tooth surface and high accuracy, together with steel reel,forged wheel and variable-frequency speed regulation system,which makes this type of crane become renewal product of traditional general bridge crane and applied in industry of machinery production,assembling, petrochemicals,warehouse logistics, electric power construction,paper making, and railways.
European hoist is a new kind of low headroom product. According to Europe standard of FEM and DIN, the product is researched and developed at the basis of general planning the lift capacity,basic structure, mechanism working system and performance parameters, and modular design idea. It applies international general structure with the characters of compact structure , high space utilization, reliability, large working scope ,smooth travelling to realize precise position to load, long life span and low maintenance expenses. We believe the product is your best choice.
Lifting capacity 1-20 ton
Shell: aluminum alloy
Working group:M3-M7
Travelling speed:5-20m/min
Hoisting height:6/9/12/18m
Hiosting speed:0.6/4.0m/min-1.6/10m/min
Brake:Double-disk electromagnetic brake
Control model:pendent control or remote control
1. Weight overload protection device
2. Top quality durable polyurethane buffer
3. Crane traveling limit switch
4. Low voltage protection function
5. Emergency stop system
6. Current overload protection function
