Parameter
|
Values
|
|
|
Useful lifting capacity, tn
|
36/40/50 ton
|
|
|
Mechanism speed, m/s (m/min)
|
lifting speed
|
0,17 (10)
|
|
carrier travelling speed
|
0,67 (40)
|
|
|
crane travelling
|
1,0 (60)
|
|
|
Spread bar rotating speed, rpm
|
1
|
|
|
Spread bar rotating angle, grad
|
±180
|
|
|
Deceleration/acceleration time to nominal speed values, s
|
lifting
|
2...3
|
|
carrier travelling
|
5...6
|
|
|
crane travelling
|
10...12
|
|
|
spread bar rotating
|
4...5
|
|
|
Speed adjustment range
in % from the nominal one
|
lifting
|
2...100
|
|
carrier travelling
|
5...100
|
|
|
crane travelling
|
5...100
|
|
|
spread bar rotating
|
5...100
|
|
|
Loading mode according to ISO 4301-1:1986 (load distribution factor)
|
Q3 (Kp=0,5)
|
|
|
Utilization class according to ISO 4301-1:1986 (maximum number of cycles)
|
U5 (5 *105)
|
|
|
Crane classification type in general according ISO 4301-1:1986
|
A6
|
|
|
Total running time of the mechanism according to
ISO 4301-1:1986
|
lifting
|
T6 (12500 machine hours)
|
|
carrier travelling
|
T6 (12500 machine hours)
|
|
|
crane travelling
|
T5 (6300 machine hours)
|
|
|
spread bar rotating
|
T5 (6300 machine hours)
|
|
|
Loading mode according to
ISO 4301:1-1986
|
lifting
|
L3
|
|
carrier travelling
|
L3
|
|
|
crane travelling
|
L3
|
|
|
spread bar rotating
|
L3
|
|
